PACKAGE PROTOTYPING MEDIA
Films, foils, papers, polyester, pouches, vinyls, cardboard. CGS Real Substrate Proofing. High quality package prototyping media, at highly competitive prices.
PackPROOF clear film – 85µm polyester
50 metre rolls, 24″ or 44″
| Typical value | Tested | |
| Total thickness | 142 µm | electronic micrometer |
| Total weight | 189 gm3 | internal method |
| Light transmission | >90% | ACS CS-5 Chroma SensorC, 2° observer, 600 nm |
| Usage | 10-30°C, 30-70 % RH | |
| Storage | 10-30°C, 20-50 % RH | |
| Shelf life | 18 months |
PackPROOF heat-transferable (90°) transfer film – 40µm
30 metre rolls, 24″ or 48″
| Weight | 164 | ±10 | g/m2 | ISO 536 |
| Thickness | 135 | ±10 | µm | ISO 4593 |
| Weight without liner | 48 | ±§0 | g/m2 | CAQ-PA-29.doc |
| Thickness without liner | 40 | ±10 | µm | CAQ-PA-30.doc |
| Roughness Sheffield back | 250 | ±150 | SU | ISO 8791-3 |
Transfer film without liner Color (D50, 2°)
| L | 97,1 | ±2 | — | CAQ-PA-70.doc |
| a | 0,1 | ±1 | — | |
| b | 0,1 | ±1,5 | — | |
| Haze | 5 | ±5 | % | CAQ-PA-70.doc |
PackPROOF matte embossing foil
30 metre rolls, 24″
| Value | Tolerance | Unit | Tested | |
| Weight | 176 | ±10 | g/m2 | ISO 536 |
| Thickness | 189 | ±15 | µm | ISO 534 |
| Gloss (60°) | 10,6 | % | ISO 2813 |
PackPROOF polyester clear shrink foil, 40 µm, emulsion 40 µm
30 metre rolls, 24″
| Nominal Value | Min | Max | Unit | Tested | |
| Weight | 218 | 198 | 238 | g/m2 | ISO 536 |
| Thickness | 175 | 155 | 195 | µm | ISO 4593 |
| Weight without liner | 100 | 85 | 115 | g/m2 | CAQ-PA-29.doc |
| Thickness without liner | 80 | 65 | 95 | µm | CAQ-PA-30.doc |
| Release force | 11 | 3 | 19 | cN/50mm | FTM 3 |
Transfer film without liner
| Nominal Value | Min | Max | Unit | Tested | |
| Haze | 6 | 2 | 10 | % | CAQ-PA-29.doc |
| Shrinkage CD (15s, 85°) | 75 | 60 | 90 | % | CAQ-PA-71.doc |
| Shrinkage MD (15s, 85°) | 0 | -10 | 10 | % | based on ASTM D2732 |
Storage conditions
| Temperature | 10-30° C |
| Humidity | 20-70% RH |
PackPROOF semi-matte embossing foil for transfer film
30 metre rolls, 24″
| Value | Tolerance | Unit | Tested | |
| Weight | 105 | ±7 | g/m2 | ISO 536 |
| Thickness | 75 | ±5 | µm | ISO 4593 |
| Gloss 60° (front) | 23 | % | DIN 67530 | |
| Transparency | 77 | % | ASTM D 1003-61 Method A | |
| Haze | 100 | % | ASTM D 1003-61 Method A | |
| Coefficient of friction (static) | 0,4 | DIN 53375 | ||
| Roughness Ra value | 510 | nm | DIN 4768 |
| Value | Unit | Tested | |
| Shrinkage MD (15nin, 150°) | 1,1 | % | DIN 40634 |
| Shrinkage CD (15nin, 150°) | 0,1 | % | DIN 40634 |
| Tear strength MD | 170 | N/mm2 | ISO 527-1/3 |
| Tear strength CD | 200 | N/mm2 | ISO 527-1/3 |
| Elongation at break MD | 145 | % | ISO 527-1/3 |
| Elongation at break CD | 110 | % | ISO 527-1/3 |
PackPROOF semi-matte paper – double-sided polyethylene coated
235 g/m3
45 metre rolls, 24″ or 30″ or 54″
| Value | Tolerance | Unit | Tested | |
| Weight | 216 | ±20 | g/m2 | ISO 536 |
| Thickness | 210 | ±20 | µm | ISO 534 |
| Gloss (60°) | 25 | ±6 | % | ISO 2813 |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 95,5 | ±1,0 | ISO 13655 – X-Rite 528 (M0) |
| a | 0,3 | ±1,5 | ||
| b | 0 | ±1,0 |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 96 | ±1,5 | ISO 13655 – i1 Pro 2 (M1) |
| a | 0 | ±1,0 | ||
| b | 0 | ±2,0 |
PackPROOF glossy paper – double-sided polyethylene coated
235 g/m3
45 metre rolls, 24″ or 30″ or 54″
| Value | Tolerance | Unit | Tested | |
| Weight | 245 | ±20 | g/m2 | ISO 536 |
| Thickness | 238 | ±20 | µm | ISO 534 |
| Gloss (60°) | 83 | ±10 | % | ISO 2813 |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 94 | ±1,5 | ISO 13655 – X-Rite 528 (M0) |
| a | 0,4 | ±1 | ||
| b | -4,5 | ±2 |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 4,7 | ±1,5 | ISO 13655 – i1 Pro 2 (M1) |
| a | 0,46 | ±1,0 | ||
| b | -4,8 | ±2,0 |
PackPROOF transparent pouch film – heat-sealable
65 µm
45 metre rolls, 24″ or 48″
| Value | Min | Max | Unit | Tested | |
| Weight | 235 | 215 | 255 | g/m2 | ISO 536 |
| Weight without liner | 71 | 61 | 81 | g/m2 | CAQ-PA-29.doc |
| Thickness | 232 | 212 | 252 | µm | ISO 534 |
| Thickness without liner | 64 | 54 | 74 | µm | CAQ-PA-30.doc |
| Haze | 8 | 5 | 11 | % | CAQ-PA-69.doc |
Storage conditions
| Temperature | 10-30°C |
| Humidity | 20-70% RH |
PackPROOF metallized pouch film – heat-sealable
65 µm
45 metre rolls, 24″ or 48″
>90
| Value | Min | Max | Unit | Tested | |
| Weight | 245 | 225 | 265 | g/m2 | ISO 536 |
| Weight without liner | 77 | 67 | 87 | g/m2 | CAQ-PA-29.doc |
| Thickness | 237 | 227 | 257 | µm | ISO 534 |
| Thickness without liner | 67 | 57 | 77 | µm | CAQ-PA-30.doc |
| Gloss (85° front) | >90 | — | — | % | ISO 2813 |
Storage conditions
| Temperature | 10-30°C |
| Humidity | 20-70% RH |
PackPROOF white pouch film – heat-sealable
75 µm
30 metre rolls, 24″ or 48″
>90
| Value | Min | Max | Unit | Tested | |
| Weight | 250 | 230 | 270 | g/m2 | ISO 536 |
| Weight without liner | 85 | 75 | 95 | g/m2 | CAQ-PA-29.doc |
| Thickness | 245 | 225 | 264 | µm | ISO 534 |
| Thickness without liner | 75 | 65 | 85 | µm | CAQ-PA-30.doc |
| Gloss (85° front) | >82 | — | — | % | ISO 2813 |
Storage conditions
| Temperature | 10-30°C |
| Humidity | 20-70% RH |
PackPROOF white metallized pouch film – heat-sealable
75 µm
30 metre rolls, 24″ or 48″
| Value | Min | Max | Unit | Tested | |
| Weight | 264 | 254 | 274 | g/m2 | ISO 536 |
| Weight without liner | 90 | 85 | 95 | g/m2 | CAQ-PA-29.doc |
| Thickness | 254 | 244 | 264 | µm | ISO 534 |
| Thickness without liner | 77 | 74 | 80 | µm | CAQ-PA-30.doc |
| Gloss (85° front) | 80 | 75 | 85 | % | ISO 2813 |
| ISO-Brightness (front) | *81 | — | — | % | ISO 2470-1 |
| Flatness without liner | 5 | -5 | 15 | mm | CAQ-PA-36.doc |
| Gloss (85° front) | 5 | 2 | 8 | cN/50mm | FTM 3 |
Color X-Rite 528 Mo (D50/2°) front
| Value | Min | Max | Tested | |
| L | 91,0 | 89,5 | 92,5 | ISO 13655 |
| a | -0,5 | -2,0 | 1,0 | |
| b | -4,0 | -6,0 | 2,0 |
Storage conditions
| Temperature | 10-30°C |
| Humidity | 20-70% RH |
CGS’s Real Substrate Proofing – the competitive package prototyping option.
High quality proofing media.
Very competitively priced.
#GetSerious, get in touch for pricing.
PackPROOF glossy, adhesive polyester film – solvent-based acrylate
75 µm
50 metre rolls, 24″
| Value | ||
| Adhesion force when applied to glass | 1,5 N/25mm approx | Initially |
| Thickness | 3,5 N/25mm approx | After 24 hours |
| Thickness | 75 µm | Liner |
| 95 µm | Liner with inkjet coating | |
| 155 µm | Film with liner | |
| Core diameter | 76 mm | |
| Weight | 190 g/m3 | |
| Shelf life (Indoor use, applied to inside of glass surface) | 4 years | DIN ISO 4892-3 |
| Shelf life (Outdoor use, applied to outside of glass surface) | 8 months | Depends on ink |
PackPROOF glossy white adhesive vinyl.
100 µm ±5%
40 metre rolls, 30″ or 54″
| Measure | |
| Thickness | 100 µm ±5% |
| Adhesive | Clear, water soluble, permanent |
| Adhesion | 4.7 N/cm ±5% |
| Liner | One-sided clay-coated silicone paper (135 g/m2) |
| Tensile strength MD | 8,8 KN/m |
| Tensile strength CD | 5,0 KN/m |
| Temperature stability | -20° to 50°C |
| Fire retardent | B1 |
PackPROOF matte white adhesive vinyl – wide gamut, ultra-quick drying
100 µm ±5%
50 metre rolls, 30″ or 54″
| Measure | |
| Thickness | 100 µm ±5% |
| Adhesive | Clear acrylic dispersion, permanent |
| Adhesion | 6.5 N/cm (Finat FTM1, after 24 hours on stainless steel) |
| Shrinkage | <0,4mm (Finat FTM 14) |
| Liner | One-sided clay-coated silicone paper (135 g/m2) |
| Tensile strength | > 20 MPa MD/CD(DIN EN ISO 527) |
| Elongation | > 160% MD / 180% CD (DIN EN ISO 527) |
| Application temperature | > 10° |
| Fire retardent | B1 |
Storage conditions
| Measure | |
| Temperature stability | -40° to +80° |
| Outdoor durability | 4 years, unprinted material, vertical outdoor exposure, normal central European climate |
| Shelf life | 2 years when stored in original packaging at 20° to 25° and 50% to 55% humidity |
PackPROOF semi-matte cardboard
280 g/m3
50 sheets, 61 x 86cm
| Value | Tolerance | Unit | Tested | |
| Weight | 280 | ±20 | g/m2 | ISO 536 |
| Thickness | 320 | ±25 | µm | ISO 534 |
| Flatness | 5 | ±10 | mm | CAQ-PA-43.doc |
| Gloss 60° (front) | 14 | ±5 | % | ISO 2813 |
| Stiffness MD | 2500 | ±250 | mN | ISO 1493-1 15°; 10mm |
| Stiffness CD | 1300 | ±200 | mN |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 95,5 | ±1,5 | ISO 13655 – X-Rite 528 (M0) |
| a | 1,2 | ±0,8 | ||
| b | 1 | ±1,5 |
| Value | Tolerance | Tested | ||
| Color (D50, 2°) | L | 96,5 | ±1,5 | ISO 13655 – i1 Pro 2 (M1) |
| a | 0,8 | ±0,8 | ||
| b | -1 | ±1,5 |
Package prototyping – proofing media for all mockups
Package prototyping media isn’t rocket science. Yes, quality is vital, but you also need media you can afford – sustainable, low prices.
You name it, we’ve got it – film, foils, vinyl, pouches – all the package prototyping media you need, at a price that’s hard to beat.
This is PackPROOF -CGS’s Real Substrate proofing material range, the ideal complement to CGS’s exceptional proofing paper.
Email us – tell us what you use, we’ll come back to you with direct pricing on the CGS euqivalent stock. COMPetitive pricing. 😉
CGS Media: Please note, all technical specifications for package prototyping media are subject to change. For compliance purposes, manufacturer-approved spec sheets will be supplied on request.
